Move ahead with the power to do more
-
Semi Elliptical Leaf Spring
Suspension
-
4200 mm
Wheelbase
-
325 Nm
Maximum Torque
-
497TCIC
Engine
LP 709
The Tata Motors LP 709 bus is designed to meet your passenger transport demands with utmost efficiency. The bus is designed to be deployed for different use cases. It is a reliable school bus, intercity bus, and staff bus. Its dependable Tata 497TCIC BS-II water-cooled direct injection diesel engine with intercooler delivers a maximum power of 90 HP at 2400 rpm and a torque of 325 nm.
Its 5-speed GBS-27 synchromesh gearbox ensures smooth gear transitions, enhancing the overall travel experience for its occupants. The dual circuit, full air S-CAM brake system features a 325mm Dia. provides reliable and responsive braking capabilities to maximize safety while ensuring comfort. The suspension system, consisting of semi-elliptical leaf springs at the front and rear, ensures a stable ride for passengers.
- Water cooled direct injection Diesel Engine with Intercooler
- 90 HP Maximum Power
- Tata 5 Speed GBS-27 synchromesh
- Dual Circuit, Full Air S-CAM Brake System with a 325mm Dia.
With optimized wheelbase of 4200 mm, this bus provides ample room for passengers to travel in comfort. Experience dependable performance and reliability with the Tata Motors 709, built to meet your transportation needs efficiently.
Features designed for performance and profits
01LP 709 specifications
Engine
TATA 497TCIC BS-II
Engine Type
Water cooled direct injection Diesel Engine with Intercooler
Engine Capacity
3783 cc
Max Engine Output
66.3 Kw @ 2400 rpm
Cylinders / Displacement
4 Cylinder inline / 3783 cc
Max Speed
89 kmph
Torque
325 Nm @ 1300-1600 rpm
Gradeability
26%
Gear Box
5 Speed GBS-27 synchromesh
Clutch
280 mm Dia Single plate dry friction type, booster assisted
Steering System
Integral hydraulic power assisted steering
Brakes
Dual circuit full air S-Cam brake
Suspension
Semi Elliptical leaf springs at front and rear
Suspension - Front
Semi Elliptical leaf springs
Suspension - Rear
Semi Elliptical leaf spring
Tyre Size
7.50x16, 16PR
Length
7745 mm
Width
2140 mm
Height
2550 mm
Wheelbase
4200 mm
Turning Circle Radius
14600 mm
GVW
7490 kg
Kerb Weight
2665
Fuel Tank Capacity
160 litres
Battery
12 V,150 Ah capacity
Alternator
65AMPS
Seats
30+D
Warranty
1 Years / 64,000 Kms
