Move ahead with the power to do more
-
15%
Gradeability
-
BS IV
Emission
-
700 Nm
Engine Power
-
Cummins ISBe5.9
Engine
SIGNA 3718.T
With the powerful and reliable Tata Motors SIGNA 3718.T truck, no cargo will be too heavy. Powered by a Cummins ISBe5.9 water-cooled direct injection turbocharged intercooled diesel engine with E-viscous fan, this truck delivers exceptional performance with maximum fuel efficiency. It offers a maximum power output of 179 HP at 2500 rpm and a torque of 700 nm at 1500 rpm.
The truck features a Tata G 950, 6F + 1R gearbox for smooth gear shifting and optimal control. Both driver and cargo safety is our top priority, which is why the Tata SIGNA 3718.T truck comes equipped with a Full Air S-Cam brake system with Automatic Adjuster and ABS (Anti-lock Braking System). A parabolic leaf spring at the front and a semi-elliptical leaf spring at the rear provides excellent stability, enhances load-bearing capacity, and absorbs shocks and vibrations for a smooth and controlled ride. With a gradeability of 15%, the SIGNA 3718.T cargo truck effortlessly tackles moderate slopes and inclines. Further, it also comes with a fully air-conditioned cabin for enhanced driver comfort and productivity.
- Water-Cooled Direct Injection Turbocharged Intercooled Diesel Engine With E-viscous Fan
- 179 HP Maximum Power
- Tata G 950, 6F + 1R Gearbox
- Full Air S-Cam Brake System with Automatic Adjuster and ABS System
From its dependable engine and efficient transmission to its advanced braking system and robust suspension, this truck is designed to exceed expectations and take your business to new heights.
Features designed for performance and profits
01SIGNA 3718.T specifications
Engine
Cummins ISBe5.9
Engine Type
Water cooled direct injection Turbo charged intercooled Diesel Engine with E-viscous fan
Engine Capacity
5883
Engine Power
179 HP @ 2500 RPM
Max Speed
80
Emission
BS IV
Torque
700 Nm at 1500 RPM
Gradeability
15%
Gear Box
TATA G 950, 6F +1 R
Clutch
380
Brakes
Full Air S-Cam with Automatic Adjuster & ABS
Suspension
Parabolic leaf spring at front and semi elliptical leaf spring at rear.
Tyre Size
10R20-16PR
Axle - Rear
RA-110 LD at RFWD and RA-909 at RRWD
Axle Final ratio
6.14
Wheelbase
6750 mm
Ground Clearance
278 mm
Turning Circle Diameter
23.8 mm
GVW
37000 kg
Kerb Weight
9730 kg
Max Permissible FAW
18000 kg
Max Permissible RAW
19000 kg
Fuel Tank Capacity
300
Cabin Ventilation
AC
